WAN Interface • 1 10/100BASE-TX Ethernet port for cable or DSL modem or private Ethernet line LAN Interface • 1 10/100BASE-TX Ethernet port WLAN Interface • IEEE 802.11n (up to 300Mbps) • IEEE 802.11b/g Antenna • Two 5dBi detachable omnidirectional antennas • RP-SMA connector Frequency Range • 802.11b     ◦ 2400 ~ 2497MHz ISM band • 802.11g     ◦ 2400 ~ 2483.5MHz ISM band • 802.11n     ◦ 2400 ~ 2483.5MHz ISM band Modulation Schemes • 802.11b: DQPSK DBPSK DSSS CCK • 802.11g: BPSK QPSK 16QAM 64QAM with OFDM • 802.11n: BPSK QPSK 16QAM 64QAM with OFDM Operation Modes • Access point mode • Router mode Network Functions • WAN connection types     ◦ PPPoE     ◦ Static IP     ◦ Dynamic IP     ◦ Static IP + PPPoE     ◦ Dynamic IP + PPPoE     ◦ PPTP/L2TP + Static IP     ◦ PPTP/L2TP + Dynamic IP • DHCP server/relay • DNS relay • VPN pass-through (PPTP/L2TP) • Dynamic DNS • Static IP routing • Remote management • Network statistics for each interface • IGMP Proxy • RIP • Support of UPnP IGD • WAN ping respond • Support of SIP • Support of RTSP • PPPoE pass through Wireless Connection • Supported security settings     ◦ WEP     ◦ WPA/WPA2 Personal     ◦ WPA/WPA2 Enterprise • MAC filter • Managing connected stations • PIN and PBC methods of WPS • WMM (Wi-Fi QoS) • Advanced settings • WDS • “Client” function (access point mode)     ◦ Wireless network client     ◦ Wireless network repeater • “Client” function (router mode)     ◦ WISP repeater Firewall Functions • Network Address Translation (NAT) • Stateful Packet Inspection (SPI) • IP filters • URL filter • MAC filter • DMZ • Prevention of ARP and DDoS attacks • Virtual servers Configuration and Management • Multilingual web-based interface for configuration and management • Access via TELNET • Firmware update via web-based interface • Automatic notification on new firmware version • Saving/restoring configuration to/from file • Support of remote logging • Automatic synchronization of system time with NTP server and manual time/date setup • Ping function • Traceroute utility נתונים פיזיים LEDs • Power • WLAN • WPS • LAN • Internet Power • External power adapter DC 12V/0.5А Buttons • Power on/off button • WPS/RESET button Operating Temperature • From 0 to 40 Storage Temperature • From -20 to 65 Operating Humidity • From 10% to 90% non-condensing Storage Humidity • From 5% to 95% non-condensing
