POWER AC adapter input 100-240V ~ 50/60Hz 0.4A AC adapter output 12V ⎓ 1.2A HARDWARE FEATURES Processor Qualcomm CPU Interface 2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit Button 1 Reset button on the underside External Power Supply 12 V/1.2 A Dimensions Φ3.6 in. x 7.5 in. (Φ90.7 mm x 190 mm) Antenna Type 2 internal dual-band antennas per Deco unit WIRELESS FEATURES Wireless Standards IEEE 802.11 ac

/a 5 GHz IEEE 802.11 b/g

2.4 GHz Frequency 2.4 GHz and 5 GHz Signal Rate 300 Mbps on 2.4 GHz 867 Mbps on 5 GHz Transmit Power FCC: <30 dBm CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) Wireless Security WPA-PSK/WPA2-PSK Advanced Functions ● Router/ Access Point Mode ● Optional Ethernet Backhaul ● Guest network ● TP-Link Mesh Technology: MU-MIMO Auto Path Selection Self-Healing AP Steering Band Steering Beamforming SOFTWARE FEATURES Quality of Service WMM IPv6 Support WAN Type Dynamic IP/Static IP/PPPoE/L2TP/PPTP Management Local Management Remote Management DHCP Server Client Port Forwarding Support Access Control Blacklist Firewall Security SPI Firewall Protocols Supports IPv4 and IPv6 Advanced Features Parental Controls Quality of Service Advanced Functions Monthly Reports Auto FW Update Expand Wi-Fi by adding more Deco units Guest Network 2.4 GHz guest network x 1 5 GHz guest network x 1 Beamforming Support APP Easy setup via Deco App OTHERS Certification CE FCC IC NCC BSMI IDA RCM JPA JRF VCCI KC RoHS Package Contents ● Deco M4 (3-pack): 3 Deco units 1 RJ45 Ethernet Cable 3 power adapters 1 quick installation guide ● Deco M4 (2-pack): 2 Deco units 1 RJ45 Ethernet Cable 2 power adapters 1 quick installation guide ● Deco M4 (1-pack): 1 Deco unit 1 RJ45 Ethernet Cable 1 power adapter 1 quick installation guide Smartphone/Tablet Requirements iOS 9.0 or later Android 4.3 or later Environment Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
