Radios 2.4 GHz 802.11b/g

/ax client access radio 5 GHz 802.11a

/ac/ax client access radio 2.4 GHz and 5 GHz dual-band WIDS/WIPS spectrum analysis and location analytics radio 2.4 GHz Bluetooth Low Energy (BLE) radio with Beacon support Concurrent operation of all four radios Max aggregate frame rate: 1.7 Gbps Supported frequency bands (country-specific restrictions apply): 2.412-2.484 GHz 5.150-5.250 GHz (UNII-1) 5.250-5.350 GHz (UNII-2) 5.470-5.600 5.660-5.725 GHz (UNII-2e) 5.1725-5.825 GHz (UNII-3) Antenna Integrated omni-directional antenna (5.4 dBi gain at 2.4 GHz 6 dBi gain at 5 GHz) Individual antenna elements for each radio 802.11ax 802.11ac Wave 2 and 802.11n Capabilities UL/DL-OFDMA UL-OFDMA TWT support BSS coloring 2×2 multiple input multiple output (MIMO) with 4 spatial streams SU-MIMO UL MU-MIMO and DL MU-MIMO support Maximal ratio combining (MRC) and beamforming 20 and 40 MHz channels (802.11n) 20 40 and 80 MHz channels (802.11ac Wave 2) Up to 1024 QAM on both 2.4 GHz and 5 GHz bands Packet aggregation Power Power over Ethernet: 37-47 V (802.af compliant) Alternative 12 V DC input Power consumption: 15 W max (802.3af) Power over Ethernet injector and DC adapter sold separately Interfaces 1x 10/100/1000 BASE-T Ethernet 1× DC power connector (5.5 mm × 2.5 mm center positive) Mounting All standard mounting hardware included Desktop ceiling and wall mount capable Ceiling tile rail (9/16 15/16 or 1 1/2"; flush or recessed rails) assorted cable junction boxes Bubble level on mounting cradle for accurate horizontal wall mounting Physical Security Two security screw options included Kensington lock hard point Concealed mount plate with anti-tamper cable bay Environment Operating temperature: 32 °F to 104 °F (0 °C to 40 °C) Humidity: 5 to 95% non-condensing Physical Dimensions 9.84” x 4.72” x 1.42” (25 cm x 12 cm x 3.6 cm) not including deskmount feet or mount plate Weight: 17.35 oz (0.5 kg) Security Integrated Layer 7 firewall with mobile device policy management Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal Flexible guest access with device isolation VLAN tagging (802.1Q) and tunneling with IPSec VPN PCI compliance reporting WEP* WPA WPA2-PSK WPA2-Enterprise with 802.1X WPA3 - Personal WPA3 - Enterprise WPA3 - Enhanced Open (OWE) EAP-TLS EAP-TTLS EAP-MSCHAPv2 EAP-SIM TKIP and AES encryption Enterprise Mobility Management (EMM) and Mobile Device Management (MDM) integration Cisco ISE integration for guest access and BYOD posturing Quality of Service Advanced Power Save (U-APSD) WMM Access Categories with DSCP and 802.1p support Layer 7 application traffic identification and shaping Mobility PMK OKC and 802.11r for fast Layer 2 roaming Distributed or centralized Layer 3 roaming Analytics Embedded location analytics reporting and device tracking Global L7 traffic analytics reporting per network per device and per application Warranty Lifetime hardware warranty with advanced replacement included Ordering Information MR36-HW: Meraki MR36 Cloud Managed 802.11ax AP MA-PWR-30W-XX: Meraki AC Adapter for MR Series (XX = US/EU/UK/AU) MA-INJ-4-XX: Cisco Meraki 802.3at Power over Ethernet Injector (XX = US/EU/UK/AU) MA-INJ-5-XX: Cisco Meraki 802.3at Power over Ethernet Injector (XX = US/EU/UK/AU) Note: Meraki access point license required
