IN THE BOX Aruba Instant On AP17 Access Point Aruba Instant On AP17 Quick Start guide Cable gland Wall mount bracket (solid surface) M4X6 screw M6X45 screw Copper lug RADIOS Dual radio for simultaneous dual-band operation 5 GHz 802.11ac 2x2 MIMO for up to 867 Mbps wireless data rate with Multi User MIMO support (Wi-Fi 5) 2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4) INTERFACES 10/100/1000 BASE-T Ethernet (RJ45) Bluetooth Low Energy (BLE) radio LED status indicator Reset button PHYSICAL SPECIFICATIONS Dimensions 156mm x 67mm x 187mm (excluding mount accessories) Weight 650g POWER Power over Ethernet (PoE): 802.3af power consumption 13.5W max ANTENNAS Two dual-band omni- directional antennas (4.7 dBi gain at 2.4 GHz 4.2 dBi gain at 5 GHz) MOUNTING The access point ships with a mount bracket can be mounted on the wall or a pole COMPLIANCE AND SAFETY IEC 60950/62368 CB ENVIRONMENTAL & RELIABILITY   IP55 Enclosure Operating temperature -40° C to +50° C (-40° F to +122° F) Humidity 5% to 93% non-condensing MTBF 300khrs (34yrs) at +25° C INDUSTRY CERTIFICATIONS WPA2 WPA3 Enhanced Open (OWE) Wi-Fi Alliance certified (WFA) 802.11ac Wave 2 (Wi-Fi5) MANAGEMENT OPTIONS Instant On mobile application (Android & iOS) Cloud Portal: Portal.ArubaInstantOn.com WARRANTY & SUPPORT Aruba Instant On 1 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products
