HARDWARE FEATURES Interface 3 RJ45 LAN Ports 1 RJ45 LAN/WAN Port 1 RJ11 Port 1 USB 2.0 Port Button WPS Button Wireless On/Off Button Power On/Off Button Reset Button Power Supply 12V/1.5A IEEE Standards IEEE 802.3 IEEE 802.3u 802.3ab VDSL2 Standards ITU G.993.2 Up to 17a prole (POTS) ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP) ADSL Standards Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT) ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs) ITU-T G.995.1 ADSL2 Standards ITU-T G.992.3 (G.DMT.bis) ITU-T G.992.4 (G.lite.bis) ADSL2+ Standards ITU-T G.992.5 Dimensions ( W x D x H ) 243×160.6×32.5mm Antenna Type 3 fixed external antennas Compatibility NBN - Fibre to the Node (FTTN) - DSL Modem Router Mode. NBN - Fibre to the Building (FTTB) - DSL Modem Router Mode. NBN - Fibre to the Premises (FTTP) - Wireless Router Mode. NBN - Fibre to the Home (FTTH) - Wireless Router Mode. For further information on NBN connections please visit: http://www.nbnco.com.au/learn-about-the-nbn

etwork-technology.html WIRELESS FEATURES Wireless Standards IEEE 802.11a

/ac 5GHz  IEEE 802.11b/g

2.4GHz Wireless Speeds 867Mbps at 5GHz 300Mbps at 2.4GHz Transmit Power 2.4GHz <20dBm(EIRP) 5GHz <23dBm(EIRP) Wireless Functions Enable/Disable Wireless Radio WDS Bridge WMM  Wireless Statistics Wireless Security 64/128-bit WEP WPA/WPA2 WPA-PSK/WPA-PSK2 encryptions Wireless MAC Filtering Wireless Schedule Support 2.4GHz and 5GHz Wireless Schedule SOFTWARE FEATURES Quality of Service ATM QoS Bandwidth Control Security NAT Firewall Access Control IP and MAC Address Binding Operating Modes VDSL/ADSL Modem Router Wireless Router3G/4G Router Management Web Based Conguration(HTTP) Remote management command Line Interface SSL for TR-069 SNMP v1/2c Web Based Firmware Upgrade Diagnostic Tools DHCP Server Client DHCP Client List Address Reservation DHCP Relay Port Forwarding Virtual Server Port Triggering DMZ ALG UPnP Dynamic DNS DynDns NO-IP VPN Pass-Through PPTP L2TP IPSec Passthrough Protocols Supports IPv4 and IPv6 ATM/PPP Protocols ATM Forum UNI3.1/4.0 PPP over ATM (RFC 2364) PPP over Ethernet (RFC2516) IPoA (RFC1577/2225) MER\IPoE (RFC 1483 Routed) Bridge (RFC1483 Bridge) PVC – Up to 8 PVCs Advanced Functions Parental Control Network Address Translation(NAT) Port Mapping(Grouping) Static Routing RIP v1/v2(optional) DNS Relay DDNS IGMP V1/V2/V3 USB Sharing Support Samba(Storage)/FTP Server/Media Server/Printer Server 3G/4G Modem Guest Network 2.4GHz guest network 5GHz guest network IPSec VPN Supports up to 10 IPSec VPN tunnels Beamforming 5GHz OTHERS Certification CE RoHS Package Contents · AC1200 Wireless VDSL/ADSL Modem Router Archer VR400 · External Splitter · RJ11 DSL Cable · RJ45 Ethernet Cable · Power Adapter · Quick Installation Guide System Requirements · Microsoft Windows XP/7/8/8.1/10 MAC OS NetWare UNIX or Linux · Internet Explorer Firefox Chrome Safari or other Java-enabled browser · Subscription with an Internet Service Provider (for Internet access) Warranty Limited 3-Year Warranty For further information on our warranty policy please visit: http://www.tp-link.com.au/support/rma Environment · Operating Temperature: 0℃~40℃ (32℉ ~104℉) · Storage Temperature: -40℃~70℃ (-40℉ ~158℉) · Operating Humidity: 10%~90% non-condensing · Storage Humidity: 5%~90% non-condensing
