HARDWARE FEATURES Interface 3 10/100Mbps LAN Ports 1 10/100Mbps LAN/WAN Port 1 SIM Card Slot Button WPS/Reset Button Wireless On/Off Button Power On/Off Button Antenna 3 Internal Wi-Fi Antennas  2 Detachable External 4G LTE Antennas External Power Supply 12V/1A Dimensions ( W x D x H ) 7.95 x 5.55 x 1.32 in. (202 x 141 x 33.6 mm) WIRELESS FEATURES Wireless Standards IEEE 802.11ac

/a 5GHz IEEE 802.11b/g

2.4GHz Frequency 2.4GHz and 5GHz Signal Rate 300Mbps at 2.4GHz 433Mbps at 5GHz Reception Sensitivity 5GHz: 11a 54M: -74dBm 11ac HT20: -67dBm 11ac HT40: -64dBm 11ac HT80 : -60dBm 11n HT20: -71dBm 11n HT40: -70dBm 2.4G: 11g 54M: -76dBm 11n HT20: -73dBm 11n HT40: -67dBm Transmit Power CE: <20dBm(2.4GHz) <23dBm(5GHz) Wireless Functions Enable/Disable Wireless Radio WDS Bridge WMM Wireless Statistics Wireless Security 64/128-bit WEP WPA/WPA2 WPA-PSK/WPA2-PSK encryptions Network Type (V2) 4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz) TDD-LTE B38/B39/B40/B41 (2600/1900/2300/2500MHz) 3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz) 2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz) Network Type 4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz) TDD-LTE B38/B40 (2600/2300MHz) 3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz) 2G: EDGE/GPRS/GSM Quad Band (850/900/1800/1900MHz) SOFTWARE FEATURES Quality of Service Trafc Control(IP QoS) Operating Modes 3G/4G Router Wireless Router WAN Type Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) Management Access Control Local Management Remote Management DHCP Server Client DHCP Client List Address Reservation Port Forwarding Virtual Server Port Triggering UPnP DMZ Dynamic DNS DynDns NO-IP VPN Pass-Through PPTP L2TP IPSec Access Control Parental Control Local Management Control Host List Access Schedule Rule Management Firewall Security DoS SPI Firewall IP Address Filter/Domain Filter  IP and MAC Address Binding Protocols Supports IPv4 and IPv6 Guest Network 2.4GHz guest network x 1 5GHz guest network x 1 IPSec VPN Supports up to 10 IPSec VPN tunnels OTHERS Certification CE FCC RoHS Package Contents AC750 Wireless Dual Band 4G LTE Router Archer MR200 RJ45 Ethernet Cable Power Adapter Quick Installation Guide Micro to Standard SIM Card Adapter Nano to Standard SIM Card Adapter System Requirements Microsoft Windows 98SE NT 2000 XP Vista™ or Windows 7 8 8.1 MAC OS NetWare UNIX or Linux Internet Explorer 11 Firefox 12.0 Chrome 20.0 Safari 4.0 browers or higheror other Java-enabled browsers SIM Card Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
