HARDWARE FEATURES Interface 4 10/100Mbps LAN ports 1 10/100Mbps WAN port Button WPS/Wi-Fi Button Reset Button Power On/Off Button Antenna 2 × 2.4GHz Antennas 1 × 5GHz Antenna External Power Supply 9V/0.6A(EU) 9V/0.85A(US) Dimensions ( W x D x H ) 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm) WIRELESS FEATURES Wireless Standards IEEE 802.11ac

/a 5GHz IEEE 802.11b/g

2.4GHz Frequency 2.4GHz and 5GHz Signal Rate 5GHz: Up to 433Mbps 2.4GHz: Up to 300Mbps Reception Sensitivity 5GHz: 11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm; 11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9: -62dBm 2.4GHz: 11g 54M: -76dBm11n; HT20 MCS7: -73dBm; 11n HT40 MCS7: -71dBm Wireless Functions Enable/Disable Wireless Radio WDS Bridge WMM Wireless Statistics Wireless Security 64/128-bit WEPWPA / WPA2WPA-PSK/ WPA2-PSK encryption Transmission Power CE: <20dBm(2.4GHz) <23dBm(5GHz) SOFTWARE FEATURES Quality of Service WMM Bandwidth Control Management Access Control Local Management Remote Management Port Forwarding Virtual Server Port Triggering UPnP DMZ Dynamic DNS DynDns Comexe NO-IP VPN Pass-Through PPTP L2TP IPSec Access Control Parental Control Local Management Control Host List Access Schedule Rule Management Firewall Security DoS SPI Firewall IP Address Filter/Domain Filter IP and MAC Address Binding Protocols Supports IPv4 and IPv6 Guest Network 2.4GHz guest network × 1 5GHz guest network × 1 OTHERS Certification CE RoHS Package Contents AC750 Wireless Dual Band Router Archer C20 Power Adapter RJ45 Ethernet Cable Quick Installation Guide Box Dimensions (W X D X H) 14 x 8.8 x 2.7 in. (357x223x68mm) System Requirements Microsoft Windows XP/Vista/7/8/8.1/10 MAC OS UNIX or Linux Internet Explorer Firefox Chrome Safari or other Java-enabled browsers Cable or DSL or Fiber Modem/Terminal Subscription with an Internet Service Provider (for Internet access) Environment Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
