Management Type Web Managed Number of Ports 12 10GbE SFP+ 4 10GbE SFP+/RJ45 Combo Ports 8 Note: The 10GbE SFP+ ports are backward compatible with 1GbE SFP; the RJ45 (copper) combo port supports up to five speeds (10G/5G/2.5G/1G/100M). Management Port 1 x 1GbE RJ45 Power Supply Description Internal Power Supply Unit Max. Power Consumption 70W Input Power Type AC Input Voltage Range 100 ‒ 240VAC 50/60Hz MAC Address Table 32K Total Non-Blocking Throughput 120Gbps Switching Capacity 240Gbps Management Interface Web Console RS232 Energy Efficient Ethernet (IEEE 802.3az complaint)   Fan System: 4 x 4 cm (12V) Supported Standards IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5G/5GBase-T IEEE 802.3an 10G BASE-T IEEE 802.3z 1000BASE-SX/LX IEEE 802.3ae 10G Fiber IEEE 802.3x Full-Duplex Flow Control IEEE 802.1Q VLAN Tagging IEEE 802.1w RSTP IEEE 802.3ad LACP IEEE 802.1AB LLDP IEEE 802.3az Energy Efficient Ethernet (IEEE 802.1p Class of Service) LED Indicators Per Port: Speed/Link/Activity Per System: Power/Status Buttons Reset button Dimensions (HxWxD) 46.65 x 285 x 236.6 mm Weight (Net) 2.2 kg Operating Temperature 0°C to 40°C (32°F to 104°F) Relative Humidity 5%–95% (non-condensing) Certifications FCC CE VCCI BSMI RCM WEEE Electromagnetic Compliance CLASS A Jumbo Frames 9K Warranty 2 Years
