Interface • 5 10/100/1000Base-T ports LEDs • Power • Link/Activity/Speed (per port) Port Standards & Functions • IEEE 802.3 10Base-T • IEEE 802.3u 100Base-TX • IEEE 802.3ab 1000Base-T • IEEE 802.1p QoS (4 Queues Strict Mode) • IEEE 802.3x Flow Control • ANSI/IEEE 802.3 NWay auto-negotiation • IEEE 802.3az Energy-Efficient Ethernet (EEE) • Auto MDI/MDIX adjustment for all ports Full/Half Duplex • Full/half duplex for 10/100 Mbps speeds • Full duplex for Gigabit speed D-Link Green Features • Power saving by link status and cable length Performance Switching Capacity • 10 Gbps Switching method • Store and forward MAC Address Table Size • 2K Entries MAC Address Learning • Automatic Update Maximum 64-byte Max.packet Forwarding Rate • 7.44 Mbps Packet Buffer • 128 KB Jumbo Frame • 9216 bytes Physical/Environmental Dimensions (W x D x H) • 91 x 73 x 22 mm Weight • 80 g Power • 5 V/1 A Power Adapter
