Device Interfaces • Eight 10/100 Mbps LAN ports Standards • IEEE 802.3 10BASE-T • IEEE 802.3u 100BASE-TX • IEEE 802.3x Flow Control • IEEE 802.3az Energy-Efficient Ethernet (EEE) Switching Capacity • 1.6 Gbps switching fabric Advanced Features • Auto MDI/MDIX crossover for all ports • Secure store-and-forward switching scheme • Full/half-duplex for Ethernet/Fast Ethernet speeds • Supports 2048 byte jumbo frames • Back pressure at half-duplex operation • Wire-speed reception and transmission • Store and-Forward switching method • Auto-negotiation for each port • EEE compliant IEEE 802.3 10BASE-T • IEEE 802.3u 100BASE-TX • IEEE 802.3az EEE • IEEE 802.3x flow control Data Transfer Rates • Ethernet: • 10 Mbps (half duplex) • 20 Mbps (full duplex) • Fast Ethernet: • 100 Mbps (half duplex) • 200 Mbps (full duplex) Transmission Method • Store-and-forward MAC Address Table Size • 2000 Packet Filtering/Forwarding Rates • Ethernet: 14880 pps per port • Fast Ethernet: 148800 pps per port RAM Buffer • 96 KB per device
